Elap Linear Position Sensor (Incremental) Used

Article no.: PD100120PP1
12 months guarantee
Linear Position Sensor (Incremental)  Used
Linear Position Sensor (Incremental)  Used
Linear Position Sensor (Incremental)  Used
Linear Position Sensor (Incremental)  Used
Linear Position Sensor (Incremental)  Used
Linear Position Sensor (Incremental)  Used
All images are original images.
249,00 € net*
In stock: 1 piece
Article no.: PD100120PP1
Product condition: Used
Shipping: Express delivery possible
Guarantee in months: 12
Stock: 1
* Prices excl. VAT plus shipping costs

Used item. New Items and other variants available upon request.

Specifications
Resolution: 0.01 mm
Measuring length (Stroke): 120 mm
Pulses per stroke: 3,000
Supply voltage: 12–24 VDC
Outputs: Push-pull
Output signals: Square wave A and B signals, 90-degree phase shift
Zero-point reference: Square-wave signal at stroke center
Protection class: IP64
Max. speed: 60 m/min
Max. acceleration: 40 m/sec²
Dimensions (without accessories) approx.: 31 mm x 31 mm x 285 mm
Accessories included: 6-pin Plugs with solder contacts, 2 mounting brackets

Specification

Product condition
Used
Function
Verified
Manufacturer
Elap
Guarantee in months
12
Weight
0.394 kg
Stock location
Rosenfeld
Stock ground
A18A03-BFL
