Berger Lahr Power drive for 3-phase stepping motors TLD011F PULSE/-

Article no.: 0063401100001
12 months guarantee
Power drive for 3-phase stepping motors TLD011F PULSE/-
Power drive for 3-phase stepping motors TLD011F PULSE/-
Power drive for 3-phase stepping motors TLD011F PULSE/-
Power drive for 3-phase stepping motors TLD011F PULSE/-
Power drive for 3-phase stepping motors TLD011F PULSE/-
Power drive for 3-phase stepping motors TLD011F PULSE/-
All images are original images.
380,00 € net*
In stock: 1 piece
? Display cart in PayPal
Article no.: 0063401100001
Product condition: Used
Shipping: Express delivery possible
Guarantee in months: 12
Stock: 1
* Prices excl. VAT plus shipping costs

Used item. Tested.

Specification
Supply voltage: 230VAC -20%/+15%
Logic supply voltage: 20-30VDC ≤ 1.5A
Motor phase current (settable): 0.4-3.0ARMS
Steps/revolution (settable): 200, 400, 500, 1000, 2000, 4000, 5000, 10000
Automatic current reduction at pulse frequencies: <10Hz IN x 0.7
Signal input (PULSE-C): RS422 voltage compatible, asymmetrical 4,5V bis 30V
Signal input resistance: 5kΩ, Signal outputs: Open collector ≤ 30V, max. 50mA
Dimensions (in mm): 81 x 213 x 185, Weight: ca. 2.2Kg

Specification

Product condition
Used
Manufacturer
Berger Lahr
Guarantee in months
12
Weight
2.2 kg
Stock location
Rosenfeld
Stock ground
PB11C1-BFL
