SITI Gear motor MNHLF25/2-11.92-MS80.1-4

Article no.: 415029
12 months guarantee
Gear motor MNHLF25/2-11.92-MS80.1-4
Gear motor MNHLF25/2-11.92-MS80.1-4
Gear motor MNHLF25/2-11.92-MS80.1-4
Gear motor MNHLF25/2-11.92-MS80.1-4
Gear motor MNHLF25/2-11.92-MS80.1-4
Gear motor MNHLF25/2-11.92-MS80.1-4
All images are original images.
526,00 € net*
In stock: 1 piece
? Display cart in PayPal
Article no.: 415029
Product condition: New from old stock
Shipping: Express delivery possible
Guarantee in months: 12
Stock: 1
* Prices excl. VAT plus shipping costs


Mounting type: B5 (flange-mounted motor)

Insulation class: F

Operating mode: S1 (continuous operation)

Power factor (cos φ): 0.75

Efficiency: IE1 – 67% (standard efficiency according to EN 60034)

Specification

Product condition
New from old stock
Manufacturer
SITI
Guarantee in months
12
Frequency
50 Hz
Rotation Speed
1370 rpm
Power
0,55 kW
Voltage
230 / 400 V
Current
2,74 / 1,58 A
Protection Class (IP)
IP 55
Shaft Diameter
25 mm
Shaft End
with feather key
Feather Key
8 mm x 40 mm
Flange Diameter
130 mm
Diameter Of Pitch Circle
4 x 165 mm
Speed (gear)
117 rpm
Transmission
i = 11,92
Torque
44 Nm
Weight
8.046 kg
Stock location
Rosenfeld
Stock ground
P20D2
